ADM-XL Series VFFS for Animal and Gardening Products
Manufactured Locally in Victoria Australia, the large model Vertical Form Fill Seal (VFFS) machine brings several advantages, especially for high-volume packaging needs. These machines can handle larger quantities of product per cycle, significantly increasing throughput and efficiency. They are ideal for bulk packaging, reducing the frequency of refills and downtime. Additionally, large VFFS models often come with advanced features such as enhanced sealing capabilities and more robust construction, ensuring durability and reliability even in demanding industrial environments. This makes them a cost-effective investment for businesses looking to scale up their operations while maintaining high standards of packaging quality and consistency.
- For animal feeds, they are also suitable for packaging soil, fertilizers, seeds, and other gardening products and more
- For Gardening supplies, they are also suitable for packaging soil, fertilizers, seeds, and other gardening products and more.
Features
- MADE IN AUSTRALIA
- Pack dry products
- Servo Motor Controlled Film Pull Belts
- Servo Motor Controlled Jaw Seal Actuation
- Panasonic Touch Screen Operator Interface
- Panasonic PLC – Based Control System
- Ethernet/IP Central Control system
- SMC Pneumatics Advanced Integration
- Vacuum Belt Drive
- Pneumatic balancing
- Safety Guarding and Interlocks to AS4024
Optional Elements
- Nitrogen gas flush systems
- Hole punch (Round or Euro)
- Vacuum assist units
- Static eliminators
- Gusseted device
- Special End-Seal Configurations
- Pillow bags
- Block Bottom bags
- Gas Flush
- Vacuum seal
- Impulse seal
- Continuous seal
Specifications
| Model | ADM-XLi400 | ADM-XLi600 | ADM-XLi800 | |
| Motion | Intermittent | |||
| Environment | Suitable for dry and harsh environment | |||
| Construction | Mild Steel | |||
| Bag Type | Pillow, Block bottom | |||
| Bag Size | 120-400(W) x Up to 550(L) |
200 –600(W) x Up to 900(L) |
250-800(W) x Up to 1200(L) | |
| Speed | Up to 80bpm | Up to 40bpm |
Up to 20bpm | |
| Power Supply | 415V, 50Hz, 5kW |
415V, 50Hz, 6kW |
415V, 50Hz, 7kW | |
| Air Pressure | 0.4cum/min, 0.6MPa |
0.5cum/min, 0.6MPa |
0.6cum/min, 0.6MPa | |
| Machine Dimension | 1560(W) x 2545(L) x 2230(H) mm |
1850(W) x 2880(L) x 2450(H) mm |
2150(W) x 3200(L) x 2850(H) mm | |
| Weight | 1200kg | 2000kg | 2500kg | |
